KIA Niro: Power Door Locks
Power Door Locks / Components And Components Location
- Driver power window switch
- Assist power window switch
- Integrated Gateway & Power control Module (IGPM)
- Door lock knob
- Tailgate latch assembly
- Door latch assembly
- Door lock/unlock switch
- Rear left power window switch
- Rear right power window switch
